DIN H Section Column Beam Q235 Q355 Poultry Farm Structure

Name: DIN H Section Column Beam Q235 Q355 Poultry Farm Structure
Brand: Hongfa
Price: 1 USD

Buy cheap DIN H Section Column Beam Q235 Q355 Poultry Farm Structure product

Brand Name : Hongfa

Model Number : HFP005

Certification : ISO, BS, AWS

Place of Origin : CHINA

MOQ : 1ton

Price : Neogtiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 5000 metric ton per month

Delivery Time : 10 working days

Packaging Details : By 20GP or 40HQ container

Material Steel Grade : Q235,Q345,A36,S355

Welding Standard : GB, AISI, ASTM, JIS, DIN

Main Materials : H section Steel Columns & Beams

Bracing parts : C/Z Section steel, round bars

Building size : Customer's Requirements

Surface treatment : Galvanized or Anti-rusty paint

Building Type : Light Steel Structure, Chicken Poultry Farm

Usage : Chicken or Vegetable Warehouse

Installation : Engineers Guidance

Accesossories : Common & High Strength Bolts

Contact Now

Hot Sales Steel Frame With H Section Column & Beam For Poultry Farm Structure

General Description

Poultry Farm Structure use pre-fabricated steel H beams to build the main steel frames and use galvanized C & Z beams as the roof and wall purlin, cladding systerm can do the FRP walls,or use colored steel wall and roof , or can use ASA roof & Wall materaial.

Specification
Items		Specification
Main Steel Frame	Column	Q235, Q345 Welded H Section Steel
Main Steel Frame	Beam	Q235, Q345 Welded H Section Steel
Secondary Frame	Purlin	Q235 C and Z purlin
	Knee brace	Q235 Angle Steel
	Tie Rod	Q235 Circular Steel Pipe
	Brace	Q235 Round Bar
	Vertical and Horizontal Support	Q235 Angle Steel, Round Bar or Steel Pipe
Maintenance system	Roof Panel	EPS Sandwich Panel / Glass Fiber Sandwich Panel /
	Roof Panel	Rock Wool Sandwich Panel / Pu Sandwich Panel /Steel Sheet
	Wall Panel	Sandwich Panel / Corrugated Steel Sheet
Accessories	Window	Aluminiumn Alloy Window / PVC Window / Sandwich Panel Window
	Door	Sliding Sandwich Panel Door / Rolling Metal Door / Personal Door
	Rainspout	PVC
Live load on Roof		In 120kg/Sqm (Color steel panel surrounded)
Wind Resistance Grade		12 Grades
Earthquake-resistance		8 Grades
Structure Usage		Up to 50 years
Temperature		Suitable temperature.-50°C~+50°C
Certification		ISO9001:2015
Finishing Options		Vast array of colors and textures available
Paint Options		Alkyd paiting, two primary painting, two finish painting
Paint Options		(gray paint, red paint, white paint, epoxy zinc etc.) Or Galvanized.

DIN H Section Column Beam Q235 Q355 Poultry Farm Structure

Characteristics
1. Wide span: single span or multiple spans, the max span is 36m without middle column
2. Low cost and maintenance: unit price range from USD25/m2 to USD65/m2 according to customers request
3. Fast construction and easy installation: time saving and labor saving
4. Long using lifespan: up to 50 years
5. Nice appearance
6. Others: environmental protection, stable structure, High quake-proof, water proof and fire proof, and energy conserving.

Quotation Need

Compay Name:
Client	Tel/Fax:			E-mail:
Building Basic Information
Project:				Project No.:
Location	Building Usage				Total area
Length (m)	Width (m)				Eave Height (m)
Roof material
Wall material
Design Load and Meteorological Conditions
Wind load (kn/m²)	Wind speed (m/sec)				Snow load (kn/m²)
Rainfall Capacity	Earthquake Grade
Please fill out the below information if your building has the mezzanine
Height of Mezzanine(m)			Usage of mezzanine
Live load on mezzanine(kn/m²)
Please fill out the below information if your building has the crane
Capacity (t)	Span (m)				Quantity
Hoisting height (m)		Other information about crane
